Building a Production RAG Pipeline: From PDFs to Claude Agent Knowledge Base in 60 Minutes

By the end of this tutorial, you’ll have a working production RAG pipeline with Claude that ingests PDFs, chunks and embeds them, stores vectors in a local database, and answers questions with grounded citations — deployable in under 60 minutes. No LangChain magic you can’t debug, no black-box abstractions. Just Python, anthropic, chromadb, and pypdf.

This is the stack I’d actually use for a first production deployment: minimal dependencies, observable at every step, and extensible without a full rewrite when requirements change.

1. Install dependencies — Set up Python environment with the four libraries you actually need
2. Extract text from PDFs — Parse PDFs and handle encoding edge cases cleanly
3. Chunk the text — Split with overlap so context doesn’t get cut at chunk boundaries
4. Generate embeddings — Use OpenAI’s text-embedding-3-small to vectorize chunks
5. Store vectors in ChromaDB — Persist the index locally with metadata attached
6. Build the retrieval function — Query by semantic similarity and return ranked chunks
7. Wire up the Claude agent — Feed retrieved context into Claude with a grounded system prompt

Step 1: Install Dependencies

Keep the dependency surface small. You need four packages: anthropic for the Claude API, chromadb for local vector storage, pypdf for PDF parsing, and openai for embeddings (OpenAI’s embedding models are better value per token than Voyage for most use cases).

pip install anthropic chromadb pypdf openai python-dotenv

Pin your versions in requirements.txt. ChromaDB in particular has had breaking API changes between minor versions:

anthropic==0.34.2
chromadb==0.5.5
pypdf==4.3.1
openai==1.45.0
python-dotenv==1.0.1

Step 2: Extract Text from PDFs

PDF parsing fails more than you’d expect. Scanned documents return empty strings. Some PDFs have ligatures that mangle search. Handle these upfront rather than debugging silent failures downstream.

from pypdf import PdfReader
from pathlib import Path

def extract_pdf_text(pdf_path: str) -> list[dict]:
    """
    Returns a list of dicts: {"page": int, "text": str, "source": str}
    Skips pages with fewer than 50 characters (likely scanned/blank).
    """
    reader = PdfReader(pdf_path)
    source_name = Path(pdf_path).stem
    pages = []

    for i, page in enumerate(reader.pages):
        text = page.extract_text() or ""
        text = text.strip()

        if len(text) < 50:
            # Warn but don't crash — scanned pages are common
            print(f"Warning: page {i+1} of {source_name} may be scanned or empty")
            continue

        pages.append({
            "page": i + 1,
            "text": text,
            "source": source_name
        })

    return pages

Step 3: Chunk the Text

This is the step most tutorials get wrong. Naive sentence splitting at 512 tokens destroys context when a sentence spans the end of one chunk and the start of another. Use a sliding window with overlap — 20% overlap is a reasonable starting point, tweak based on your document type.

def chunk_text(pages: list[dict], chunk_size: int = 600, overlap: int = 120) -> list[dict]:
    """
    Splits page text into overlapping chunks.
    chunk_size and overlap are in characters, not tokens.
    Rule of thumb: 1 token ≈ 4 chars, so 600 chars ≈ 150 tokens.
    """
    chunks = []

    for page in pages:
        text = page["text"]
        start = 0

        while start < len(text):
            end = start + chunk_size
            chunk_text = text[start:end]

            # Don't create tiny trailing chunks
            if len(chunk_text) < 50:
                break

            chunks.append({
                "text": chunk_text,
                "source": page["source"],
                "page": page["page"],
                "chunk_id": f"{page['source']}_p{page['page']}_c{len(chunks)}"
            })

            start += chunk_size - overlap  # slide forward with overlap

    return chunks

For legal docs or dense technical manuals, I’d push chunk_size up to 900-1000 chars. For FAQ-style docs with short answers, drop to 300. There’s no universal right answer — retrieval quality is the test. See our guide on semantic search and embeddings for how to benchmark retrieval quality on your specific corpus.

Step 4: Generate Embeddings

Using text-embedding-3-small at $0.02 per million tokens. Embedding a 100-page PDF with ~300 chunks costs less than $0.001. Run this once per document and persist.

import os
from openai import OpenAI
from dotenv import load_dotenv

load_dotenv()
oai_client = OpenAI(api_key=os.environ["OPENAI_API_KEY"])

def embed_chunks(chunks: list[dict], batch_size: int = 100) -> list[dict]:
    """
    Adds 'embedding' key to each chunk dict.
    Batches requests to stay under API limits.
    """
    texts = [c["text"] for c in chunks]
    all_embeddings = []

    for i in range(0, len(texts), batch_size):
        batch = texts[i:i + batch_size]
        response = oai_client.embeddings.create(
            model="text-embedding-3-small",
            input=batch
        )
        all_embeddings.extend([e.embedding for e in response.data])

    for chunk, embedding in zip(chunks, all_embeddings):
        chunk["embedding"] = embedding

    return chunks

Step 5: Store Vectors in ChromaDB

ChromaDB gives you persistent local vector storage with no infrastructure overhead. For production with 100k+ chunks you’d want Qdrant or Pinecone, but for most deployments ChromaDB handles it fine and is significantly easier to operate.

import chromadb

def build_vector_store(chunks: list[dict], collection_name: str = "knowledge_base") -> chromadb.Collection:
    """
    Creates or loads a persistent ChromaDB collection.
    Re-running with the same collection_name will skip existing IDs.
    """
    client = chromadb.PersistentClient(path="./chroma_db")

    # get_or_create avoids duplicate errors on re-runs
    collection = client.get_or_create_collection(
        name=collection_name,
        metadata={"hnsw:space": "cosine"}  # cosine similarity for text
    )

    # Filter out chunks already in the collection
    existing_ids = set(collection.get()["ids"])
    new_chunks = [c for c in chunks if c["chunk_id"] not in existing_ids]

    if not new_chunks:
        print("All chunks already indexed.")
        return collection

    collection.add(
        ids=[c["chunk_id"] for c in new_chunks],
        embeddings=[c["embedding"] for c in new_chunks],
        documents=[c["text"] for c in new_chunks],
        metadatas=[{"source": c["source"], "page": c["page"]} for c in new_chunks]
    )

    print(f"Indexed {len(new_chunks)} new chunks.")
    return collection

Step 6: Build the Retrieval Function

This is the “R” in RAG. Query the vector store with an embedded version of the user’s question, return the top-k most similar chunks. The n_results parameter is a tuning knob — more results means more context for Claude but higher token cost per query.

def retrieve_context(
    query: str,
    collection: chromadb.Collection,
    n_results: int = 5
) -> list[dict]:
    """
    Returns top-n relevant chunks for a query.
    Each result includes text, source filename, and page number.
    """
    # Embed the query using the same model as the documents
    response = oai_client.embeddings.create(
        model="text-embedding-3-small",
        input=[query]
    )
    query_embedding = response.data[0].embedding

    results = collection.query(
        query_embeddings=[query_embedding],
        n_results=n_results,
        include=["documents", "metadatas", "distances"]
    )

    chunks = []
    for doc, meta, dist in zip(
        results["documents"][0],
        results["metadatas"][0],
        results["distances"][0]
    ):
        chunks.append({
            "text": doc,
            "source": meta["source"],
            "page": meta["page"],
            "similarity": 1 - dist  # convert cosine distance to similarity
        })

    return chunks

Filter out chunks below a similarity threshold (I use 0.4 as a floor) to avoid injecting irrelevant noise into the prompt. Hallucination from low-quality retrieval is a bigger problem than hallucination from the model itself — worth reading our strategies for reducing LLM hallucinations in production if this is a concern for your use case.

Step 7: Wire Up the Claude Agent

Now the production RAG pipeline Claude integration. The key is a system prompt that explicitly tells Claude to cite sources and refuse to answer if the context doesn’t contain relevant information. This single instruction does more to prevent hallucination than any post-processing filter.

import anthropic

claude = anthropic.Anthropic(api_key=os.environ["ANTHROPIC_API_KEY"])

SYSTEM_PROMPT = """You are a knowledgeable assistant with access to a document knowledge base.

Rules:
1. Answer ONLY based on the provided context chunks.
2. Always cite your sources using [Source: filename, p.X] format.
3. If the context doesn't contain enough information to answer, say so explicitly.
4. Do not infer or extrapolate beyond what the documents state."""

def ask_claude(query: str, collection: chromadb.Collection) -> str:
    """
    Full RAG query: retrieve relevant chunks, then ask Claude.
    """
    # Retrieve relevant chunks
    chunks = retrieve_context(query, collection, n_results=5)

    # Filter weak matches
    strong_chunks = [c for c in chunks if c["similarity"] > 0.4]

    if not strong_chunks:
        return "I couldn't find relevant information in the knowledge base for that question."

    # Format context for the prompt
    context_str = "\n\n".join([
        f"[Source: {c['source']}, p.{c['page']}]\n{c['text']}"
        for c in strong_chunks
    ])

    response = claude.messages.create(
        model="claude-3-5-sonnet-20241022",
        max_tokens=1024,
        system=SYSTEM_PROMPT,
        messages=[
            {
                "role": "user",
                "content": f"Context:\n{context_str}\n\nQuestion: {query}"
            }
        ]
    )

    return response.content[0].text

Cost estimate at current pricing: each query embeds ~50 tokens + 5 chunks of ~150 tokens = ~800 tokens context, plus the user question. With Claude 3.5 Sonnet at $3/M input tokens, a typical query costs around $0.003. At scale, swap to Claude Haiku — you’ll drop to roughly $0.0003 per query for most retrieval tasks. See our breakdown of when the Claude API vs Agent SDK makes sense for higher-volume deployments.

Putting It All Together

def build_knowledge_base(pdf_paths: list[str]) -> chromadb.Collection:
    """Index multiple PDFs into a single ChromaDB collection."""
    all_chunks = []

    for path in pdf_paths:
        print(f"Processing {path}...")
        pages = extract_pdf_text(path)
        chunks = chunk_text(pages)
        embedded = embed_chunks(chunks)
        all_chunks.extend(embedded)

    return build_vector_store(all_chunks)


if __name__ == "__main__":
    # Build the index (run once, or incrementally as new PDFs arrive)
    collection = build_knowledge_base([
        "docs/product_manual.pdf",
        "docs/faq.pdf",
        "docs/technical_spec.pdf"
    ])

    # Interactive query loop
    while True:
        query = input("\nAsk a question (or 'quit'): ").strip()
        if query.lower() == "quit":
            break
        answer = ask_claude(query, collection)
        print(f"\n{answer}")

Common Errors and How to Fix Them

Empty or garbled text from PDFs

Symptom: Chunks contain mostly whitespace, random characters, or are suspiciously short. Cause: Scanned PDFs, password-protected files, or PDFs built from images. Fix: Check len(text) < 50 as shown above. For scanned docs you’ll need OCR — pytesseract or cloud Vision APIs. For password protection, pypdf supports a password argument in PdfReader.

ChromaDB “duplicate ID” errors on re-runs

Symptom: chromadb.errors.DuplicateIDError when you run the indexer twice. Fix: The get_or_create_collection + existing ID filter in Step 5 handles this. If you’ve already got a broken collection, delete the ./chroma_db directory and re-index.

Retrieval returns irrelevant chunks

Symptom: Claude answers questions with context that’s clearly off-topic. Cause: Either your similarity threshold is too low, your chunks are too large (diluting signal), or the question phrasing doesn’t match the document vocabulary. Fix: Lower chunk_size to 400, raise the similarity filter to 0.5, and consider adding a where filter in ChromaDB to scope retrieval to specific documents. For persistent retrieval issues, adding retry logic with query reformulation is worth the 30 minutes it takes to implement.

What to Build Next

The natural extension here is multi-document routing: instead of querying a single collection, build a lightweight classifier that identifies which document category a question belongs to (product docs vs. legal docs vs. support FAQs), then routes to the appropriate ChromaDB collection before retrieval. This dramatically improves precision when your corpus spans very different domains. Combine it with Claude’s tool use to let the agent decide which collection to search based on the question — that’s the point where your RAG system starts to feel genuinely agentic rather than a glorified search box.

Bottom Line: Who Should Use This Stack

Solo founders and small teams: This exact setup — ChromaDB local + text-embedding-3-small + Claude Sonnet — is appropriate up to about 50,000 chunks (~500 dense PDFs). Total infrastructure cost is zero beyond API calls. Start here.

Teams with 100k+ chunks or multi-user concurrency: Swap ChromaDB for Qdrant (self-hosted) or Pinecone. Keep the same chunking and retrieval logic — it’s portable. The vector store is the only thing that changes.

Budget-sensitive deployments: Claude Haiku cuts per-query cost by 10x with acceptable quality degradation on most retrieval-augmented tasks. Run both on 50 representative queries and compare — for most document Q&A use cases, Haiku is good enough.

The production RAG pipeline Claude stack here is deliberately boring: no frameworks, no magic, nothing you can’t step through with a debugger. That’s intentional. The complexity should live in your data and your prompts, not in your infrastructure.
